LCD Controller Kit (Q062151011)--- E-qstore


M.NT68676.2A(HDMI+DVI+VGA+Audio) LCD/LED Screen Controller Board Diy Monitor Kit

   This is a great set of easy-reassembling LCD controller kit which is used to turn a bare LCD panel into a desktop/PC monitor. It will be a surprise that your bare LCD will be of good use, and no longer be a waste. Or it is a very insteresting things that we make a monitor successfully by ourselves.  It supports most of the LCD panel from 12.1" to 55" with a LVDS interface and a resolution lower than 2048X1152, plug&play kit, no need soldering.

    Notice: Please remember to leave us your LCD Model Number (click here to leave it ) before placing the order, it is very import for us to prepare the right kit for you

   How to find a right lcd model number? Please check the following picture. They are LTN154P1-L01, LP150X05(A2)(C1), LP171WP4(TL)(B1)and N154I2-L02 . Their sizes are 15.4", 15", 17.1" and 15.4".

  Necessary Accessories for turning a bare LCD to desktop monitor: LCD Controller board, Inverter, LVDS cable, Keypad, VGA cable/DVI Cable/HDMI cable, Power Adapter. If you have already had a VGA cable/DVI cable/HDMI cable and a power adapter (Ouput 12V,4A -- it is for small size lcd from 10.1inch to 19inch), this kit is a great choice for you, else there are some other kind of kits for options in our store, click here.

 LCD Controller Board  M.NT68676.2A:

LCD Controller Kit (Q062151011)

M.NT68676.2A is a monitor control board, which can support LED/LCD panels. It can support resolution up to 2048X1152.

M.NT68676.2A can synchronize with computer automatically. Synchronization requires the synchronous signal which horizontal and vertical sync are separated.

M.NT68676.2A can support dynamic contrast control, headphone input and digital volume control simultaneously.

Size of controller board: 139mmX58mmX17mm

LCD Controller Kit (Q062151011)

LCD Controller Kit (Q062151011)



LCD Controller Kit (Q062151011)

 If the inverter for your lcd is not among these three inverters, the price will be higher, hope for your understanding.

Have a try and you will get great surprise!

Then, are you going to get this kit?


   Important Steps to Process your order with this kit:

   Step 1: Please provide your LCD panel model no. by sending us the ebay message before bidding this item, so that we can advise a right kit for your LCD.  (Usually, the model no. can be found on a sticker on the back of the LCD panel. If needed, disassemble the plastic shell and you will find the sticker). If possible, please give us as more specification of your LCD as you can. Then wait for our reply.

   Step 2:   We will give you the reply as soon as possible after carefully selecting and testing the kit by our technical support, and then you can place the order, and pay for it. We will send the package via HongKong Post as soon as possible after cleared payment. (If you prefer express shipping, please contact us to pay additional shipping cost before payment.)

   Step 3:  Waiting for the package.

   We will write corresponding program into the lcd controller board to match your LCD, so this kit will match against one very specific LCD Panel or others that have exactly the same specification. However, a programmer could help on different LCDs, that is, change the firmware of the LCD controller board by yourself. Be aware that different LVDS cables and Inverters will be needed to match different LCDs.



   1. Please make sure that your LCD is ok before bidding this item, else you will be responsible for the incompatibility.

  2. If you concern much about resolution setting, please reconsider before bidding!

  3. We will try our best to prepare the right kit for you, such as writing the corresponding program into the controller board, selecting the suitable LVDS cable and the suitable inverter. But as we don't have an LCD exactly as yours at hand, we can just test the controller with our own LCD. For yours, you need to test it yourself to check if it works well or not. As you know, there are so many LCDs with many varieties in the market, sometimes we can't promise the exact compatibility. Please consider it before bidding! However, we have gained many success in preparing the kit for our customers in real store. So why not have a try to get surprise!

  4. If you are not specialized in electronics or have doubts in operation, please contact us for instruction, as we are not able to responsible for wrong operation.

  5. After finishing the connecting, please don't rush to power on! First, use multi-meter to test whether the GND of the LCD is connected with the GND of the controller board. If not, please check the connection again. If yes, please test whether there is a short circuit between the red wires and black wires of the LVDS cable. If there is a short circuit, it means opposite connection or other errors. Any problem, please feel free to contact us. DIY needs a certain professional knowledge, please kindly take the responsibility of the risk. No metal contact is allowed when powering on the controller board, otherwise short circuit may occur, which may cause unavailability of the controller board.

LCD Controller Kit (Q01415750)

United Kingdom Friend p33dy_b' successful example:

Poland Friend biputox's great splicing screen ( however, we don't know how to make it yet):

Germany Friend god-of-games's Successful example:

Portugal Friend jcag1986's project connected to PS3:

Germany Friend d-mantion's Project:

American Friend cryalith's Raspberry PI Computer:

LCD Controller Kit (Q01415750)

LCD Controller Kit (Q01415750)

Australian Friend beyelka's Project:

LCD Controller Kit (Q01415750)

LCD Controller Kit (Q01415750)

Successful Example (rossg77 -- an American friend's Project ):

  Successful Example (radicalboy_fr -- a French friend's Project ):

LCD Controller Kit (Q01415750)

  LCD Controller Kit (Q01415750)

Successful Example (docpot2008 -- a Canadian friend's Project ):

 LCD Controller Kit (Q01415750)

Malta Friend drac1977's Project:

LCD Controller Kit (Q01415750)

USA  Friend loafer_tingo's Project :

LCD Controller Kit (Q01415750)


Instruction to connect the controller board to the LCD (more details click here):

  No metal contact is allowed.

1. Take away the old inverter and old LVDS cable from the LCD panel.

2. Connect the new inverter and new LVDS cable to your LCD panel.

3. Connect controller board kit to the PC with VGA cable/DVI cable/HDMI cable.

4. Input power of 12V,4A. ( Please don't revised the voltage jumper setting on the lcd controller board before confirmation from us, because wrong revising of this voltage will get your lcd burnt. By the way, please don't connect the lvds cable wrongly, some wrong connection can get your lcd burnt too, if you are not sure, please feel free to contact us.)
