Encoder 600P/R Incremental Rotary Encoder AB phase encoder 6mm Shaft W coupling

　

Description:

Features:

600 p/r (Single-phase 600 pulses /R,Two phase 4 frequency doubling to 2400 pulses)

Power source: 5-24 VDC

Shaft: 6mm Dia, 13mm Length

Size: 38mm Dia, 35.5mm Length

Output :AB 2phase output rectangular orthogonal pulse circuit, the output for the NPN open collector output type

Maximum mechanical speed: 6000 R / min

response frequency: 0-20KHz

Cable length: 3 meter

Notice:AB 2phase output must not be directly connected with VCC, otherwise, will burn the output triode.

connection:

Green = A phase, white = B phase, red = power +, black = power
　

Package Contents
100% Brand New
1 pcs Encoder 600P/R Incremental Rotary Encoder

1pcs coupling

　
