MIDI Shield Breakout Board for Arduino compatible AVI PIC Digital Interface





 Description:
  • Product Details:



    MIDI note player

     This sketch shows how to use the serial transmit pin (pin 1) to send MIDI note data.
     If this circuit is connected to a MIDI synth, it will play
     the notes F#-0 (0x1E) to F#-5 (0x5A) in sequence.

     The circuit:
     * digital in 1 connected to MIDI jack pin 5
     * MIDI jack pin 2 connected to ground
     * MIDI jack pin 4 connected to +5V through 220-ohm resistor
     Attach a MIDI cable to the jack, then to a MIDI synth, and play music.
     */

    void setup() {
      //  Set MIDI baud rate:
      Serial.begin(31250);
    }

    void loop() {
      // play notes from F#-0 (0x1E) to F#-5 (0x5A):
      for (int note = 0x1E; note < 0x5A; note ++) {
        //Note on channel 1 (0x90), some note value (note), middle velocity (0x45):
        noteOn(0x90, note, 0x45);
        delay(100);
        //Note on channel 1 (0x90), some note value (note), silent velocity (0x00):
        noteOn(0x90, note, 0x00);
        delay(100);
      }
    }

    //  plays a MIDI note.  Doesn't check to see that
    //  cmd is greater than 127, or that data values are  less than 127:
    void noteOn(int cmd, int pitch, int velocity) {
      Serial.write(cmd);
      Serial.write(pitch);
      Serial.write(vel


     Package Contents
    100% Brand New

    1 xMIDI Shield Breakout Board for Arduino compatible AVI PIC Digital Interface
